Datavideo DAC-8P HD/SDI to HDMI (1080p) Converter

Rentals starting at

$45.00

Rent-A-Bit low price guarantee!

800-673-7350

Call us or click below to request a quote.

The DAC-8P is small and intelligent converter for converting HD & SD-SDI to HDMI. DAC-8P converts from both HD-SDI and SD-SDI to HDMI enabling users to utilize traditional and affordable LCD and Plasma televisions as well as video projectors for broadcast video monitoring.

PRODUCT HIGHLIGHTS:

  • Input: SDI, unbalanced audio

  • Output: HDMI, SDI (loop through)

  • Wide range DC input from 9V to 15V

  • Video output format is the same as the input format, so "what goes in, comes out"

Manufacturer

Brand DataVideo
Model DAC - 8P

General

Type SDI to HDMI Converter
Color Black

Connectivity

Input Connectors 1x 3G/HD/SD-SDI
2 x RCA (Stereo Pair)
2x SDI Audio embedded
Output Connectors 1x HDMI
with embedded Audio
2x HDMI Audio embedded

Supported Formats

Input Formats 1080p (23.98/24/25/29.97/30/50/59.94/60Hz),
1080i (50/59.94/60Hz),
720p (50/59.94/60Hz),
576i (PAL), 480i (NTSC)
Output Formats Automatically matches the SD, HD and
3G SDI video input

Physical Information

Power DC 12V, 4W
Dimensions (WHD) 112 x 85 x 45 mm
Weight 0.3 kg

Recommended Uses

Uses SDI to HDMI Converter
