Kramer VP-66ETH RGBHV 6x6 Matrix Switcher

Rentals starting at


Rent-A-Bit low price guarantee!


Call us or click below to request a quote.

The Kramer VP-66 is a high performance, 6x6 RGBHV/balanced stereo audio matrix switcher for high resolution video/VGA-XGA and balanced stereo audio signals. It is a true matrix, routing any input to any or all outputs simultaneously. Since the VP-66 can switch during the vertical interval, transitions are glitch-free when sources share a common reference sync. There are many updated features on this popular design including audio breakaway, which provides the ability to switch audio independantly from video. Eight preset memory locations are provided for quick access to common configurations. In addition, the TAKE button allows the user to place multiple switches in a queue, and then activate them with one touch of this button. There are three ways to control the VP-66: front-panel buttons, RS-232, and RS-485. It is dependable, rugged and fits in three vertical spaces of a standard 19" rack (3U). Video bandwidth of 300MHz ensures that the VP-66 remains transparent even in the most critical applications.


  • High Bandwidth - 300MHz (−3dB) fully loaded HDTV Compatible

  • Control - Front panel, RS−232 (K−RouterTM Windows®−based Kramer software is included), * RS−485, Ethernet, & IR Remote (included)

  • Take Button - Executes multiple switches all at once

  • Memory Locations - Stores multiple switches as presets to be recalled and executed when needed Audio Breakaway Switching

  • Standard 19” Rack Mount Size - 3U


Brand Kramer
Model VP-66ETH


Type Matrix Switcher


Input Connectors 6x3 video (RGB); 0.7 Vpp/75Ω on BNC connectors; 1 Sync/Video Genlock with sync select switch 1 Vpp/75Ω on a BNC connector; 6 x2 Hs & Vs, TTL level /75Ω or video 0.7 Vpp/75Ωon BNC connectors; 6 balanced stereo audio, +4 dBu/33k Ωon detachable terminal blocks.

Performance Data

Bandwidth (video output) 300 MHz fully loaded (video).
Signal Level (video output) 0.7 Vpp (RGB)
Signal/Noise (video output) Audio: 84dB unweighted, (1Vpp
